The NL0242 motor kit is the mechanical heart of NOVAL’s ATC sliding sunroof systems. Installed within the central rail, it drives the belt mechanism responsible for the precise and fluid movement of the roof panel.

Operating on a 24V DC power supply, the motor delivers a nominal current of approximately 5A, with peak start-up currents reaching up to 20A depending on installation conditions. This ensures sufficient torque to overcome environmental resistance such as wind pressure, salt buildup, or structural loads encountered at sea.

The motor is supplied ready for installation, complete with its drive output pulley and a fully assembled power cable featuring a dedicated marine-grade connector, ensuring seamless integration with the NOVAL control system.

Fully integrated into a complete system, the motor works in coordination with:

Control unit NL0129
Open position sensor NL0241
Closed position sensor NL0243

This synchronized system ensures:

Accurate and repeatable roof positioning
Protection against overtravel and mechanical stress
Extended lifespan of belts, rails, and moving components

The motor operates through a belt-driven transmission system, where correct tensioning and alignment are critical. Proper installation guarantees smooth motion, reduced wear, and consistent performance over time.

This motor is widely used across premium yacht brands equipped with NOVAL ATC sunroof systems, including Beneteau, Jeanneau, Prestige, Galeon, Sessa Marine, and Filippetti Yachts.

Features

Reference: NL0242
Function: Drive motor for ATC sliding sunroof
Power supply: 24V DC
Nominal current: ~5A
Start-up current: up to 20A
Drive system: Belt-driven central rail mechanism
Compatibility:
- Control unit: NL0129
- Open sensor: NL0241
- Closed sensor: NL0243
Protection rating: Marine-grade IP67 (salt, humidity, vibration resistant)

Compatibility

This motor is designed for NOVAL ATC sunroof systems installed on various premium yachts, including:

Beneteau – Gran Turismo range with ATC sliding sunroofs
Beneteau – Flyer 12 (Starboard sunroof sensor)
Jeanneau – Leader range with ATC sliding sunroofs (Leader 40, Leader 46, etc.)
Jeanneau – Prestige 440S
Galeon – 435 GTO with integrated ATC electric sunroof
Sessa – C42 with hardtop electric sliding roof

Installation / Maintenance

Installation

Disconnect electrical power and remove belt tension
Position the motor within the central rail assembly
Align correctly with the drive belt
Install and tension the belt evenly
Connect wiring to control unit NL0129 (yellow connector)
Install sensors NL0241 and NL0243
Perform several open/close cycles for validation

Maintenance

Check belt tension and alignment regularly
Rinse with fresh water after salt exposure
Ensure drainage systems are clear
Inspect electrical connections for corrosion
Operate periodically to maintain performance
Adjust or replace belt if irregular motion occurs
Apply silicone spray on rails and sliding components

Our review

✔ Pros

Core component ensuring reliable sunroof operation
Robust IP67 marine-grade construction
Seamless integration with NOVAL control and sensor ecosystem
Smooth and precise motion for optimal onboard comfort

✘ Cons

Requires precise installation and alignment
Dependent on full system (control unit + sensors)
High start-up current must be considered in electrical design

Conclusion

The NL0242 motor kit is the driving force behind NOVAL ATC sunroof systems. It ensures smooth, controlled, and reliable movement under all marine conditions. When properly installed and paired with its dedicated control unit and sensors, it delivers long-term performance and operational safety. A critical component for maintaining the efficiency and integrity of any ATC sliding roof system.

Good to Know

Precise rail alignment is essential to avoid excessive current draw
Incorrect belt tension can lead to premature wear or system malfunction
Always verify rail parallelism during installation
Calibration cycles are required after installation
Ensure drainage systems are functional to prevent water accumulation
Periodic maintenance significantly extends motor lifespan

English spoken

On parle Français

Call us: +33 6 33 30 44 50 Chat on WhatsApp Contact us by e-mail

NOVAL NL0242 ATC sunroof motor kit for yacht sliding roof – 24V marine IP67 drive motor system installed in rail

Top-down view of a Galeon 435 GTO yacht showing two separate sliding sunroofs, with a spacious bow sunpad area where a person is relaxing, and triple outboard engines at the stern over calm green water.

Click to enlarge

Aerial view of a Prestige 440S yacht cruising at speed with its sliding sunroof fully open, revealing the light-filled helm area, and featuring a sleek bronze-and-white hull gliding over dark water.

Couple seated together at the helm of a Jeanneau Leader 46 yacht, cruising with the sliding sunroof open, showing the modern dashboard and teak flooring beneath their feet.

Aerial view of a Beneteau Gran Turismo series yacht cruising at speed with its sliding sunroof partially open, featuring a sleek white hull, spacious foredeck sunpad, and leaving a wide wake over calm blue-green water.

Aerial view of a Beneteau Flyer 12 yacht cruising at speed with its sliding sunroof open, showing the helmsman at the wheel, a teak swim platform, and a distinctive wood-accented hull cutting through the waves.

Aerial view of a Prestige 440S yacht cruising at speed with a partially opened ATC sliding sunroof, featuring a foredeck sunpad, teak swim platform, and a passenger seated in the open cockpit.

White Sessa C42 yacht cruising near a historic waterfront castle, featuring an open panoramic sliding sunroof and sleek side windows under a clear blue sky.

ATC Sunroof Motor Kit – NL0242

The ATC sunroof motor kit NL0242 is the core drive unit of NOVAL ATC marine sliding roof systems. It ensures precise, smooth, and reliable movement of the sunroof, even in demanding offshore conditions.

Dedicated drive motor for NOVAL ATC sunroofs
Compatible with control unit NL0129 and sensors NL0241 / NL0243
Designed for harsh marine environments (humidity, salt, vibrations)
Smooth and controlled opening/closing cycles
24V DC system with optimized power consumption

Estimated delivery dates: May 8, 2026 - May 13, 2026

708.00€ ex. VAT

In stock

SKU	NL0242
