Description of the NL0885 – 2 stage boat table lift
The NL0885 electric table lift is a two-stage telescopic pedestal crafted entirely from mirror-polished 316 stainless steel, providing exceptional resistance to corrosion, humidity, and salt spray — essential for both indoor saloons and outdoor cockpit installations.
Its compact design and smooth electric movement allow seamless transformation of living spaces on board. With a vertical stroke of 270 mm, this table lift enables easy adjustment of the tabletop height, optimizing the use of available space while maintaining full stability at sea.
Operating on a 24V DC – 5A system, the NL0885 ensures quiet, precise movement, making it suitable for modern yachts and catamarans. Its internal self-locking mechanism secures the table at the desired height, providing reliable support even in rough seas.
Designed for a maximum dynamic load of 100 kg and static load of 200 kg, the pedestal offers excellent rigidity for solid tabletops used in marine furniture. The square lower deck plate and rectangular upper plate facilitate easy installation under a variety of tabletops and ensure a sturdy mount to the deck.
Specifications
- Model: NL0885
- Type: 2-stage electric table lift
- Material: Mirror-polished 316 stainless steel
- Power supply: 24V DC
- Current consumption: 5 A
- Retracted height: 404 mm
- Deployed height: 674 mm
- Stroke: 270 mm
- Rising speed: 12 mm/s
- Maximum dynamic load: 100 kg
- Self-locking (static load): 200 kg
- Lower plate dimensions: 250 × 250 mm
- Upper plate dimensions: 250 × 188 mm
- Use: Indoor / outdoor marine installations
Installation / Maintenance
Installation:
- Follow the installation instructions supplied with the lift for secure mounting.
- For wired control, use a MOM-OFF-MOM polarity-reversing switch.
- Ensure the mounting surface is perfectly level to guarantee smooth, stable operation.
Maintenance:
- Rinse regularly with fresh water to remove salt and preserve the mirror-polished finish.
- Apply silicone or lanolin spray to sliding sections to maintain smooth motion.
- Inspect electrical connections and fastenings periodically, especially after offshore use.
Our review
✔ Pros
- Premium mirror-polished 316 stainless steel construction
- Compact 2-stage design ideal for limited spaces on board
- Quiet and smooth electric operation
- High load capacity with secure self-locking system
- Suitable for indoor and outdoor marine installations
✘ Cons
- Control switch or control box not included by default
- Single-leg standard configuration
Conclusion
The NL0885 electric table lift is the perfect solution for yacht owners seeking a reliable, elegant, and space-saving table pedestal. Its mirror-polished stainless steel, precise motorized movement, and compact dimensions make it ideal for modern yachts, catamarans, and luxury motorboats. It transforms your onboard living spaces effortlessly while ensuring stability, durability, and refined marine aesthetics — a smart investment for any nautical interior.
Good to Know
- This model is also available in a synchronized version (NL0885-SYNC) for wide tabletops requiring two legs.
- For shore power or residential AC use, a suitable 110/220V to 24V DC converter is required.
- Equal cable lengths are recommended when using synchronized configurations.
- Commonly found on premium yachts such as Prestige 590 and Galeon 500 Fly.
