The FPS reinforced slide is specially designed for boat seats mounted on a solid console or pedestal, allowing pivoting from the top only. Installation is quick and easy, with a handle accessible from the seated position, which can be placed on either side during assembly. It complies with ABYC H-31 standards for type AO, ensuring safe and reliable use.
Specifications
- Height: 39 mm (1.5″)
- Weight: 4.5 kg (10 lb)
- Deck interface plate: diameter 190 mm (7.5″)
- Deck mounting holes: diameter 160 mm (6″)
- Seat interface plate: 330 x 315 mm (13″ x 12.5″) (Handles 250mm / 10″ from center line)
Installation / Maintenance
Installation of the FPS reinforced slide is quick and easy, with a handle accessible from a seated position, which can be placed on either side during assembly.
Regular maintenance is recommended to ensure optimum performance and long life.
Maintenance mainly consists of regularly checking fastenings and protecting the mechanism from the elements to ensure optimum longevity. Preventive lubrication of sliding elements is recommended twice a year. Use a silicone or lanolin spray on the system slides and actuator stem.
Our Review
Pros :
- Quick and easy installation
- Handle accessible from seated position, can be placed on either side during assembly
- Meets with ABYC H-31 standards for type AO
Cons :
- Designed for pivoting from the top only, which may limit certain applications
Conclusion
The FPS reinforced slide is an ideal solution for boat seats mounted on a console or solid pedestal, offering quick and easy installation, with an accessible handle when seated. Its compliance with ABYC H-31 standards for type AO ensures safe and reliable use.
