Description of the NL2156 – 3-stage stainless steel marine table lift
The NL2156 3-stage electric table lift in mirror-polished stainless steel 24V DC is engineered for yachts, catamarans and motorboats seeking modular and high-end interior fittings. Manufactured in mirror-polished 316 stainless steel, this telescopic pedestal ensures exceptional resistance to corrosion, making it perfectly suited for offshore and coastal cruising.
Its three-stage telescopic structure allows a generous vertical travel, enabling the transformation of a saloon table into a berth extension, sunbed or lowered coffee table. The lift operates on a 24V DC power supply (5A), ensuring reliable and efficient performance aboard vessels equipped with 24-volt electrical systems.
With a retracted height of 355 mm and a deployed height of 679 mm, the NL2156 provides a total stroke of 324 mm, offering significant flexibility in layout configuration. Its motorized actuator delivers a smooth lifting speed of approximately 15 mm/s, ensuring controlled and silent operation even in dynamic sea conditions.
The rectangular upper and lower mounting plates (320 x 320 mm 360° turn-table with locking latch) provide excellent stability and load distribution. With a maximum admissible load of 100 kg, this lift guarantees safe and secure support for solid wood, composite or stone tabletops typically found on luxury yachts.
The NL2156 can be installed as a single unit or synchronized in pairs for larger tabletops. When two pedestals are fitted beneath the same table, synchronization is achieved using the dedicated control box NL2120, ensuring perfectly parallel movement during raising and lowering operations.
Specifications
- Model: NL2156
- Type: 3-stage rectangular electric table lift
- Retracted height (A): 355 mm
- Deployed height (B): 679 mm
- Stroke: 324 mm
- Lower plate dimensions: 320 x 320 mm 360° turn-table with locking latch
- Upper plate dimensions: 320 x 320 mm 360° turn-table with locking latch
- Lifting speed: approx. 15 mm/s
- Maximum load: 100 kg
- Power supply: 24V DC – 5A
- Material: Mirror-polished 316 stainless steel
- Application: Interior and exterior marine environments
Good to Know
- The 24V DC configuration is particularly suitable for larger yachts and vessels equipped with 24-volt onboard electrical systems.
- The maximum recommended cable length between control box and lift is 5 meters, and cable lengths must be identical when two lifts are synchronized.
- A protective fuse or circuit breaker must be installed on the power supply line.
- When operating the lift, always maintain visual contact with the mechanism for safety.
Installation / Maintenance
Installation:
- For non-synchronized installations, a MOM OFF MOM polarity-reversing switch (optional reference NL1494) must be wired to control upward and downward motion.
- For synchronized dual-lift installations, the NL2120 control box (180 x 94 x 57 mm) is mandatory.
- Optional radio control solutions (integrated or external receiver with remote handset) are available for enhanced onboard comfort.
- Ensure correct protection of the 24V electrical circuit according to marine standards.
Maintenance:
- Rinse regularly with fresh water to eliminate salt deposits and preserve the mirror-polished finish.
- Apply silicone or lanolin spray on sliding sections to maintain smooth telescopic movement.
- Inspect electrical connections and mounting bolts periodically, especially after offshore passages.
- In case of actuator replacement, follow the official technical procedure to ensure proper reassembly of the three stainless steel sections.
Our review
✔ Pros
- Premium mirror-polished 316 stainless steel construction
- Generous 324 mm stroke for versatile onboard configurations
- Powerful and reliable 24V DC motorization
- Compatible with synchronized dual installation
- High load capacity (100 kg) suitable for luxury tabletops
- Designed for harsh marine environments
✘ Cons
- Requires a 24V DC onboard electrical system
- Control switch or synchronization module sold separately
- Professional installation recommended for optimal alignment
Conclusion
The NL21563-stage electric table lift is a robust and refined solution for yacht owners seeking modularity and premium finish in their saloon or cockpit. Its mirror-polished 316 stainless steel construction ensures durability at sea, while its generous lifting range allows seamless transformation of your living space. Designed for 24V DC systems and compatible with synchronized installations, it is particularly suited for large sailing yachts and motor yachts. If you are looking for reliability, elegance and flexibility in your onboard layout, the NL2156 is a safe and durable investment for long-term cruising comfort.
Good to Know
- Two NL2156 lifts can be synchronized under one tabletop using the NL2120 control box.
- Optional radio remote systems allow wireless operation from anywhere in the saloon or cockpit.
- For vessels connected to shore power only, a suitable AC/DC converter can be integrated to supply 24V DC.
- This model is the 24V DC version of the 3-stage stainless steel range, ideal for yachts equipped with 24V onboard networks.
