Description of the NL2146 – 3 stage boat table lift
The NL2146 electric table lift is a three-stage telescopic pedestal manufactured entirely from mirror-polished 316 stainless steel, offering outstanding resistance to corrosion, moisture, and salt-laden marine atmospheres — perfectly suited for both luxury yacht saloons and exposed cockpit installations. Its advanced triple-section design provides extended vertical travel while maintaining compact dimensions when retracted. With a generous stroke of 324 mm, this electric table pedestal allows effortless transformation of onboard living areas, converting a dining table into a berth or lounge configuration while ensuring optimal space management at sea. Operating on a 12V DC – 10A system, the NL2146 delivers smooth, quiet, and precise movement, fully compatible with standard onboard electrical systems. The integrated self-locking actuator mechanism secures the tabletop firmly at any chosen height, guaranteeing stability and safety even when the vessel is underway in challenging conditions. Designed to withstand demanding marine use, the pedestal supports a maximum dynamic load of 100 kg and a static self-locking load of 200 kg. Its robust construction ensures excellent rigidity for solid wood or composite tabletops commonly used in high-end yacht interiors. The wide rectangular lower and upper mounting plates provide secure fastening to the deck and tabletop, facilitating straightforward installation and reliable load distribution.
Specifications
- Model: NL2146
- Type: 3-stage electric table lift
- Material: Mirror-polished 316 stainless steel
- Power supply: 12V DC
- Current consumption: 10 A
- Retracted height: 313 mm
- Deployed height: 637 mm
- Stroke: 324 mm
- Rising speed: 15 mm/s
- Maximum dynamic load: 100 kg
- Self-locking (static load): 200 kg
- Lower plate dimensions: 355 × 280 mm
- Upper plate dimensions: 355 × 280 mm
- Use: Indoor / outdoor marine installations
Installation / Maintenance
Installation:
- Follow the installation instructions supplied with the lift to ensure proper alignment and secure deck mounting.
- For wired control, use a MOM-OFF-MOM polarity-reversing switch compatible with 12V DC systems.
- Ensure the mounting surface is perfectly level to guarantee smooth, synchronized vertical travel.
- For larger tabletops requiring two pedestals, a compatible synchronization control box is recommended.
Maintenance:
- Rinse regularly with fresh water to remove salt residues and preserve the mirror-polished marine finish.
- Apply silicone or lanolin spray to the telescopic sliding sections to maintain smooth extension and retraction.
- Periodically inspect electrical wiring, actuator connections, and mounting bolts, particularly after offshore passages.
Our review
✔ Pros
- Premium mirror-polished 316 stainless steel construction
- Extended 3-stage stroke ideal for berth conversion
- Smooth, quiet 12V DC electric operation
- High load capacity with secure self-locking system
- Suitable for indoor and outdoor marine installations
- Robust mounting plates for enhanced stability
✘ Cons
- Control switch or synchronization box not included by default
- Requires 12V DC power supply with adequate amperage
Conclusion
The NL2146 electric table lift is a premium three-stage marine pedestal designed for yacht owners who demand versatility, strength, and refined aesthetics. Its mirror-polished 316 stainless steel structure ensures long-term durability in corrosive offshore environments, while its powerful yet quiet 12V DC actuator guarantees smooth and precise adjustment. With its generous stroke and high load capacity, it is perfectly suited for transforming a saloon table into a comfortable berth. Reliable, elegant, and engineered for life at sea, the NL2146 is a smart and durable investment for any modern yacht interior.
Good to Know
- Compatible with synchronized twin-leg configurations for wide tabletops.
- Engineered specifically for harsh marine environments and salt spray exposure.
- Ideal for yacht refits and new builds requiring premium modular furniture solutions.
- For shore power or residential AC use, a suitable 110/220V to 12V DC converter is required.
