Description of the NL0886 – 2 stage electric boat table lift
The NL0886 electric table lift is a two-stage telescopic pedestal engineered specifically for demanding marine and nautical environments. Crafted entirely from mirror-polished 316 stainless steel, it offers excellent resistance to corrosion, humidity and salt spray, making it ideal for both indoor saloons and outdoor cockpits.
Thanks to its compact design and controlled electric movement, the NL0886 allows seamless transformation of onboard living spaces. With a vertical travel of 270 mm, this table leg makes it easy to convert a dining table into a lower coffee table or relaxation area, optimising space on board without compromising stability.
Operating on 24V DC – 5A, this model is particularly adapted to modern yachts and catamarans equipped with 24V electrical systems. The motorized actuator delivers smooth and quiet movement at a nominal speed of 12 mm/s, ensuring comfortable and precise height adjustment even at sea.
Designed to support a maximum dynamic load of 100 kg, the NL0886 guarantees excellent rigidity and stability for solid tabletops commonly used in marine furniture. Its internal self-locking system ensures secure positioning once the desired height is reached.
The square lower plate (250 × 250 mm) provides a stable deck fixation, while the upper plate (250 × 188 mm) allows easy installation under a wide variety of tabletops. The NL0886 can be installed as a standalone unit or, in its SYNC version, paired with a second lift for larger tables :contentReference[oaicite:1]{index=1}.
Specifications
- Model: NL0886
- Type: 2-stage electric table lift
- Material: Mirror-polished 316 stainless steel
- Power supply: 24V DC
- Current consumption: 5 A
- Retracted height: 404 mm
- Deployed height: 674 mm
- Stroke: 270 mm
- Rising speed: 12 mm/s
- Maximum dynamic load: 100 kg
- Self-locking (static load): 200 kg
- Lower plate dimensions: 250 × 250 mm
- Upper plate dimensions: 250 × 188 mm
- Use: Indoor / outdoor marine installations
Installation / Maintenance
Installation:
- Installation instructions are supplied with the table lift and should be followed carefully.
- For wired control, a MOM-OFF-MOM polarity-reversing switch is required.
- Ensure the mounting surface is perfectly level to guarantee smooth and even movement.
Maintenance:
- Rinse regularly with fresh water to remove salt residues and preserve the mirror-polished finish.
- Apply silicone or lanolin spray to the sliding sections to maintain smooth operation.
- Periodically inspect electrical connections and mechanical fastenings, especially after offshore use.
Our review
✔ Pros
- High-quality mirror-polished 316 stainless steel
- Perfectly suited for 24V DC yacht electrical systems
- Compact 2-stage design ideal for limited spaces
- Smooth and quiet electric operation
- Excellent stability and load capacity
✘ Cons
- Control switch or control box not included as standard
- Single-leg configuration for standard version
Conclusion
The NL0886 electric table lift is an excellent choice for boat owners seeking a reliable, elegant and space-saving table pedestal. Its mirror-polished stainless steel construction, compatibility with 24V systems and smooth electric movement make it perfectly adapted to modern yachts and luxury motorboats. Ideal for transforming onboard living spaces with ease, the NL0886 combines durability, functionality and refined marine aesthetics, making it a smart and long-lasting investment for any nautical interior.
Good to Know
- This model is also available in a synchronized version (NL0886-SYNC) for wide tabletops requiring two legs.
- For AC shore power or residential use, a suitable 110/220V AC to 24V DC converter is required.
- Equal cable lengths are recommended if using synchronized configurations.
- This table lift is commonly used on premium yachts and motor yachts, such as:
